1920*1200P 5500 Lumens Church Video Projectors 3LCD Laser Short Throw
$0.00$0.00(In stock)
Categories: Church Video Projectors
1920*1200P 5500 Lumens Church Video Projectors 3LCD Laser Short Throw
Real Resolution 1920*1200 5500 Lumens Large Venue 3lcd Laser Short Throw Projector For Exhibition Educational EL-TL506UT
| Brightness | ||
| Brightness | 5500 | |
| Brightness -TYP | 5000 | |
| Overall Spec | ||
| Panel | Display Panel | 3x0.64” with MLA |
| Display Technology | Liquid Crystal Display | |
| Native Resolution | WUXGA (1920 x 1200) | |
| Light source Life time | Normal mode | 20000hrs |
| ECO1 mode | 30000hrs | |
| ECO2 mode | 30000hrs | |
| Lens | Lens Vendor | RICOH |
| Projection Lens | F | F1.6 |
| f | 6.39mm | |
| Zoom/Focus | Manual | |
| Throw Ratio | 0.44:1 | |
| Zoom Ratio | N/A | |
| Screen size | 55-130 inch | |
| Lens Shift | N/A | |
| CR | Contrast Ratio (FOFO) | 5000000:1 |
| Noise | Noise(dB) | TGT: 37dB(Normal) 27dB(ECO) |
| Uniformity | Uniformity(Actual Min) -JISX6911 | 80% |
| AR | Aspect Ratio | Native:16:10 Compatible: 4:3/16:9 |
| Terminal(I/O port) | ||
| Input | VGA | *1 |
| HDMI 1.4B(IN) | *2 | |
| USB-A | *1 | |
| USB-B | *1(Display) | |
| RJ45 | *1(Display) | |
| DVI-D | N/A | |
| HD baseT | *1(Optional) | |
| HD-SDI(3G-SDI) | N/A | |
| Video | N/A | |
| Audio in (mini jack,3.5mm) | *1 | |
| Output | VGA | *1 |
| HDMI 1.4B(OUT) | N/A | |
| Audio out (mini-jack,3.5mm) | *1 | |
| Control | RS232 | *1 |
| RJ45 | *1 (Control) | |
| USB-B | *1 (For upgrade) | |
| Wired Remote(IN) | N/A | |
| Wired Remote(OUT) | N/A | |
| General Spec | ||
| Audio | Speaker | 16W*1 |
| Dust filter | W/Filter | |
| Filter Life time | 8000h | |
| Power Consumption | Power Requeirements | 100~240V@ 50/60Hz |
| Power Consumption (Normal) (Max) | 360 | |
| Power Consumption (ECO1) (Max) | 280 | |
| Power Consumption (ECO2) (Max) | 230 | |
| ECO Standby Mode Power Consumption | <0.5W | |
| Temp.&Humidity | Operating Temp. | 5 to 40deg.C |
| Operating Thumidity. | 20-80% | |
| Store Temp. | ‘-10 to 50deg.C | |
| High altitude | 0~3000m | |
| Other Functions | ||
| Keystone | Keystone Correction (Lens@center) | V: ±15° H:±15° Pincushion/Barrel Correction 6 Corner correction 4 Corner Correction Grid image tune |
| OSD | Languages | 26 languages: English, German, French, Italian, Spanish, Polish, Swedish, Dutch ,Portugese, Japanese, Simplified Chinese, Traditional Chinese, Korean, Russian, Arabic, Turkish, Finnish, Norwegian, Danish, Indonesian, Hungarian, Czech, Kazak,Vietnamese,Thai, Farsi |
| LAN Control | LAN Control-RoomView (Crestron) | Yes |
| LAN Control-- AMX Discovery | Yes | |
| LAN Control-- PJ link | Yes | |
| Scanning Frequency | H-Synch Range | 15~100KHz |
| V-Synch Range | 24~85Hz | |
| Display Resolution | Computer Signal Input | VGA, SVGA, XGA, SXGA,WXGA,UXGA,WUXGA,4K@3 0Hz |
| Video Signal Input | 480i, 480p, 576i, 576p, 720p, 1080i and 1080p | |
| SW setting | Auto Setup | INPUT SEARCH,AUTO PC,Auto Keystone |
| Blank | Yes | |
| Suspend | Yes(5miniutes no singnal as default) | |
| Picture mode | Dynamic,Standard,Cinema, Colorboard,sim-DICOM ,Blackboard(Green) | |
| Cooling time | 0s, Normal,60s | |
| Auto Ceiling | Yes | |
| D-Zoom | 1~33 | |
| Others | 360° projection | Yes |
| Edge Blending | N/A | |
| Wireless display无线投屏 (Optional) | SmartPhone: Android:Install APK for Android iphone: Airplay function PC投屏: Support WiFi Display@Windows&MAC system through dongle | |
| Dimension&Weight | ||
| MAX Dimensions (WxHxD mm) | 405*404*164mm | |
| Net. Weight (KG) | ~7.9KG | |
| Packaging Box Dimensions (WxHxD mm) | 510*498*260 | |
| Gross. Weight (KG) | ~10.4KG | |
| Accessory | ||
| Manual Languages | Chinese,English | |
| Standard Accessaries | Power cord(EU)/power cord(Ja) Remote control&RC Battery | |
| Regulation List | ||
| China | CCC | √ |
| CECP | X | |
| 中国効率規制 (2016/10-)-CEL | X | |
| WW | CB | √ |
| US | cTUVus | √ |
| FCC | √ | |
| FDA | √ | |
| EU | CE-EMC | √ |
| CE-LVD | √ | |
| CE-ERP | √ | |
| 激光等级 | class1 | √ |
| EMC Class | ||
| EMC Class | Class A@3dBm | |
